T500 Complete Distillery~Still Spirits T500~ Column & Condenser
T500 Complete Distillery~Still Spirits T500~ Column & Condenser T500 Complete Distillery~Still Spirits T500~ Column & Condenser

T500 Complete Distillery
Still Spirits T500
Column & Condenser

$969.00

The T500 Complete Distillery, including the T500 Stainless Steel Column & Condenser, is the ultimate set-up for producing quality neutral spirit to flavour with our spirit or liqueur flavourings at home. This comprehensive kit provides everything you need to create high-quality spirits, first fe...
Add ons:
  • Turbo Production Pack 8kg Still Spirits
    $63.50
  • T500 Water Flow Regulator Still Spirits
    $139.00
  • Large Copper Parrot Head Still Spirits
    $109.00

Free shipping over $125* (conditions apply).

Description

The T500 Complete Distillery, including the T500 Stainless Steel Column & Condenser, is the ultimate set-up for producing quality neutral spirit to flavour with our spirit or liqueur flavourings at home. This comprehensive kit provides everything you need to create high-quality spirits, first ferment your wash in as little as 7 days, then with approximately 4.5 hours distilling time produce a total of 8 L of 40% ABV spirits. The kit includes a selection of finest spirit and liqueur flavourings to then flavour your alcohol as you please.

The T500 Complete Distillery contains everything you need to start making and distilling alcohol. It includes the T500 Boiler and the T500 our most advanced fractionating reflux column & condenser. It also includes all the required additional equipment, ingredients and flavourings to make a range of premium spirits and liqueurs at home. Additionally, this versatile system is suitable for producing distilled water.

The T500 and T500 Boiler are made from 304-grade stainless steel, ensuring durability and longevity. The T500 is also filled with a unique combination of specialised distilling and alcohol refining saddles for superior results. The T500 is cooled by water, with connectors to fit most kitchen or laundry taps. The kit includes a needle valve threaded tap connector for superior water flow control.

Transform your home distillation experience with the T500 Complete Distillery, and enjoy the convenience and quality of crafting your own premium spirits and liqueurs with ease.

Compatibility: The T500 Boiler also fits the Still Spirits Alembic Copper Dome & Condenser and Dome (sold separately) providing additional distillation options as an alembic distilling system.

Features:
  • For intermediate distilling
  • Suitable for distilled water and neutral spirits
  • T500 & T500 Boiler made from 304-grade stainless steel
  • Designed in New Zealand
  • Faucet adaptor for ease of cooling water connection
  • Produces alcohol at up to 93% ABV
  • Boil dry reset
  • Thermal cut out fuse
  • Waste discharge tap with a stainless-steel ball valve
  • Boiler lid with 48 mm opening
  • 25 L Boiler capacity


*Legal Considerations: Distilling at home is legal in New Zealand. Check the laws in your country or state before you get started.

Specifications

CAPACITY:

  • T500 Boiler: 25 L
  • Fermenter: 30 L
  • Easy Filter System: 8 L


FERMENTATION TIME:

  • At 15°C (59°F): 9-10 days
  • At 30°C (86°F): 4-5 days


YIELD:

  • Approx. 8 L of 40% ABV per 25 L wash


PURITY:

  • Distills at up to 93% ABV before diluting to 40% ABV


DIMENSIONS:

  • T500 Stainless Steel Column & Condenser: 690 mm (h) x 160 mm (w) x 85 mm (d)
  • T500 Boiler: 640 mm (h) x 360 mm (w) x 370 mm (d)
  • Fermenter:  420 mm (h) x 420 mm (w) x 380 mm (d)
  • Easy Filter System: 725 mm (h) x 250 mm (w) x 250 mm (d)


WEIGHT:

  • T500 Stainless Steel Column & Condenser: 2.31 kg
  • T500 Boiler: 5.42 kg
  • Fermenter: 1.25 kg
  • Easy Filter System: 1.68 kg


WARRANTY:

  • T500 Stainless Steel Column & Condenser: 3 years
  • T500 Boiler: 3 years


Important Notes: The boiler lid is designed primarily for small to medium-sized distilling setups that do not have heavy, off-centre attachments. The lid is reasonably flexible and is sturdy enough to fit components that are within the following specifications:

  • A total column & condenser height up to 1.1 m (3.6 ft) from the lid.
  • A total column & condenser weight up to 11 kg (24 lbs), including up to 2 kg (4.4 lbs) of off-centre weight from a swan neck, lyne arm, or condenser running in parallel with the column and offset up to 160 mm (6”) to the main column.

We recommend external support if:

  • Your column & condenser exceeds the above specifications.
  • The lyne arm is not vertical but angled or perpendicular running away from the column, resulting in significantly distant off-centre weight.
  • If the column & condenser is noticeably leaning.

Ingredients

Still Spirits Top Shelf Select Liqueur Chocolate Rum (Invert sugar syrup, water, fructose syrup, glucose syrup, natural flavourings, colour (caramel (E150a, E150b (sulphites)), flavourings, humectant (E422); Still Spirits Top Shelf Select Liqueur Cafelua (Invert sugar syrup, fructose syrup, glucose syrup, water, natural flavourings, colour [caramel (E150d (sulphites)), (E150b (sulphites))], flavourings, humectant [E422], preservatives [sodium metabisulphite, potassium sorbate], thickener [E466]); Still Spirits Top Shelf Select Classic Whiskey (Flavouring, colour [caramel (E150d (sulphites)); Still Spirits Top Shelf Select American Bourbon (Flavourings (milk, barley), colour [caramel (E150d (sulphites)); Still Spirits Top Shelf Select Jamaican Dark Rum (Natural flavourings, water, colour [caramel (E150a, E150b, E150d)], flavourings, humectant [E422]); Still Spirits Classic 6 Turbo Yeast (Yeast nutrients, dried yeast (yeast, emulsifier (E491)), antifoaming agent, vitamins, trace minerals); Still Spirits Turbo Clear (Water, silica solution, acid (malic acid), chitosan (crustaceans), preservative (sodium metabisulphite); Still Spirits Turbo Sugar (Sugar, dextrose monohydrate (corn), carbon); Still Spirits Turbo Carbon (Water, activated carbon, thickener (xanthan gum), preservative (sodium metabisulphite); Still Spirits Distilling Conditioner (Water, silicone antifoam).

Allergens:

Contains milk, barley, sulphites and crustaceans.

What's Included

  • T500 Stainless Steel Column & Condenser
  • Copper and stainless steel saddles (pre-packed)
  • 2 x Cooling water tubes
  • Distillate tube
  • Digital thermometer
  • Ceramic boil enhancers
  • Tap adapter flow controller with kitchen and garden tap adaptors
  • T500 Instructions
  • T500 Boiler
  • T500 Boiler Instructions
  • 30 L Plastic Fermenter complete with Tap, Sediment Reducer, Airlock, Grommet and Stick On Thermometer
  • Easy Filter System
  • 5 L Measuring Jug/Collector
  • 50 cm Stirring Spoon
  • Hydrometer with trial jar
  • Alcometer
  • >Distilling Conditioner
  • >No Rinse Sanitiser 25 g
  • >Cold Water Detergent 25 g
  • >Turbo Classic 6 Yeast 142g
  • Turbo Clear 130g
  • Turbo Sugar 6 x 2kg
  • Turbo Carbon 140g
  • 3 x Top Shelf Select / Classic Spirit Flavourings
  • 2 x Top Shelf Selct / Icon Liqueurs Spirit Flavourings
